Accu-Chek Aviva User Manual

Changing the Lancet Drum
When you have used the sixth and last lancet, you should change the drum.
1. Take the black cap o the lancing device by
pulling it straight o. It is not a twist cap. The
easiest way to do this is to place your thumb to
the side of the notch as seen in the illustration.
2. Hold the drum between your thumb and index
finger and pull it straight out of the lancing
device. A red stripe is visible on the white part,
indicating that the drum has been used.
NOTE
A used drum cannot be reinserted into the lancing device.
36

Accu-Chek Aviva Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Coding	No coding required
Battery Life	Approximately 1000 tests
Memory	500 test results
Battery Type	1 x 3V lithium (CR2032)
Operating Humidity	10% to 90% RH
Meter Weight	59 g
Measuring Range	10 mg/dL to 600 mg/dL
Automatic Shut Off	After 90 seconds of inactivity
