Accu-Chek Aviva User Manual

3. Throw away the old drum. Always dispose in
accordance with local regulations.
4. Insert a new drum, white end first, until it stops. It
clicks into place.
NOTE
Once the drum is inserted into the lancing device, do not remove the drum until completely used. The
drum cannot be reinserted.
OR
37

Accu-Chek Aviva Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Coding	No coding required
Battery Life	Approximately 1000 tests
Memory	500 test results
Battery Type	1 x 3V lithium (CR2032)
Operating Humidity	10% to 90% RH
Meter Weight	59 g
Measuring Range	10 mg/dL to 600 mg/dL
Automatic Shut Off	After 90 seconds of inactivity
