Accu-Chek Compact Plus Reference Manual

21
Initial steps before testing
2
2.2.1 Type plate
The type plate on the back of your meter indicates which unit of mea-
surement your meter uses.
2.2.2 Display check
You can check the unit of measurement your meter uses by performing
a display check.
 Press and hold down the M button.
The meter turns on. While you hold down the M button, you first see the
display check.
mmol/L meter or mg/dL meter
The unit of measurement is shown in the bottom right corner of the dis-
play.
AC_CP_LCM_Manual_EN-UK final.indd 21_CP_LCM_Manual_EN-UK final.indd 21 20.6.2007 11:03:5820.6.2007 11:03:58

Accu-Chek Compact Plus Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1.5 µL
Test Time	5 seconds
Automatic Coding	Yes
Display	LCD
Measurement Method	Electrochemical
Battery Type	2 x AAA
Battery Life	Approx. 1000 tests
Data Transfer	Infrared (IR)
Storage Conditions	-25°C to +70°C
Operating Conditions	10-40°C, 10-90% RH
