Accu-Chek Compact Plus Reference Manual

102
Using the meter as an electronic notebook
5.2 Retrieving results from memory

With the meter turned off, press the M button.
The meter turns on without advancing a test strip.
Following the display check (see Chapter 2.2.2), the most recently saved
result is displayed together with the time, date and
.
Time and date at the time
of performing a test
AC_CP_LCM_Manual_EN-UK final.indd 102_CP_LCM_Manual_EN-UK final.indd 102 20.6.2007 11:04:2220.6.2007 11:04:22

Accu-Chek Compact Plus Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1.5 µL
Test Time	5 seconds
Automatic Coding	Yes
Display	LCD
Measurement Method	Electrochemical
Battery Type	2 x AAA
Battery Life	Approx. 1000 tests
Data Transfer	Infrared (IR)
Storage Conditions	-25°C to +70°C
Operating Conditions	10-40°C, 10-90% RH
