87
Rev 2.1
Configure Lead Lag Master Configuration Advanced Setting Drop Stage Detection Time Textbox
(Default: 0m30s)
x Type in desired time
This parameter determines how long drop stage condition needs to persist for drop stage to occur.
5-23.3 To Change Drop Stage Error Threshold
Configure Lead Lag Master Configuration Advanced Setting Drop Stage Error Threshold Textbox
(Default: 5F)
x Type in desired degree
This parameter determines error based on degree away from setpoint for drop stage condition to occur.
5-23.4 to change drop stage rate offset
Configure Lead Lag Master Configuration Advanced Setting Drop Stage Rate Offset Textbox (Default:
0%)
x Type in desired rate %
This parameter determines LL master requested firing rate below the minimum firing rate for drop stage condition to
occur.
5-23.5 To Change Add Stage Interstage Delay
Configure Lead Lag Master Configuration Advanced Setting Drop Stage Interstage Delay Textbox
(Default: 0m30s)
x Type in desired time
This parameter specifies the minimum time that the stager waits before dropping a stage.
5-24 Miscellaneous Configuration
5-24.1 To Change Alarm Silence Time
Configure System Configuration Alarm Silence Time Textbox (Default: 0m0s)
x Type in desired time between 0 to 5 minutes
5-24.2 To Enable Or Disable Pre-Ignition Interlock
Configure Burner Control Interlocks PII Enable Textbox (Default: Disabled)
x Select Enable to enable Pre-Ignition Interlock
x Select Disable to disable Pre-Ignition Interlock
5-24.3 To Change Anti Short Cycle Time
Configure System Configuration Anti Short Cycle Textbox (Default: 0m0s)
x Type in desired time between 0 to 5 minutes
Whenever the burner is turned off due to no demand the anti-short cycle timer is started and the burner remains in a
Standby Delay condition waiting for this time to expire. Does not apply, however, to recycle events or DHW demand.
5-24.4 To Change Burner Name
Configure System Identification & Access Boiler Name Textbox (Default: Boiler 1)
This parameter allows each boiler to have a unique name of up to 20 characters.
5-24.5 To Change Installation Data
Configure System Identification & Access Installation Textbox (Default: Atlas)
The installer may edit this parameter to provide installation information of up to 20 characters.
5-24.6 To Change Temperature Units
