Acer Aspire V3-471 - CPU Processor Installation

3-34 Machine Maintenance Procedures
CPU Processor Installation 0
1. Place CPU processor (B) on the mainboard. Refer to Figure 3-32.
2. Tighten the cam lock (A) to the locked position (Figure 3-31).
3. Install Thermal Module.
