Hardware Specifications and Configurations 1-29
CPU Fan True Value Table
System Memory
Memory Combinations
Temperature (°C) Fan Speed (RPM) SPL Spec (dBA)
Fan on = 40°C; Fan Off = 35°C 2400 28
Fan on = 50°C; Fan Off = 45°C 2600 31
Fan on = 62°C; Fan Off = 55°C 3000 34
Fan on = 72°C; Fan Off = 67°C 3300 37
Fan on = 86°C; Fan Off = 80°C 3600 40
Fan on = 94°C; Fan Off = 90°C 5V N/A
Throttling 50%: On =96°C; Off=93°C
OS Shut down: 99°C
H/W Shut down: 100°C
Item Specification
Memory controller Built in at CPU
Memory size DDR3 1333/1600 4 GB Z(512 Meg x 64)
DIMM socket number 2 sockets
Supports memory size per socket 4 GB
Supports maximum memory size 8 GB
Supports DIMM type
SDRAM memory interface design
Note: Processor supports up to 1600 Mhz only
Supports DIMM Speed 1333/1600 SODIMM
Support DIMM voltage 1.5V±0.075V
Supports DIMM package Standard JEDEC 204-pin
Slot 1 (MB) Slot 2 (MB) Total Memory (MB)
0 2048 2048
2048 0 2048
2048 2048 4096
4096 0 4096
0 4096 4096
4096 4096 8192
