Acer H5350 - Chapter 2 Disassembly Process; Equipment Needed & Product Overview

H5350
Condential
2-1
Chapter 2
Disassembly& Assembly Process
2-1 Equipment Needed & Product Overview
1. Screw Bit (+) :107
2. Hex Sleeves 5mm
3. Screw Bit (+) :102
4. Screw Bit (-) :102
5. Long Nose Nipper
6. Tweezers
7. H5350 unit
* Before you start: This process is protective level II. Operators should wear electrostatic chains.
* Note: If you need to replace the main board, you have to get into service mode and record the
lamp usage hour. please refer to section 2-20.
