4. Pull up the Main Board Module and then
unplug 1 connector(As green square)
5. Disassemble Main Board Module and I/O
Cover Module
6. Unscrew 3 screws to disassemble I/O
Cover Module from Main Board Module
I/O Cover Module
Main Board Module
