H5350
Condential
4-5
Inspection item - Dark blemish check.(dirty)
Criteria - The bright blemish is unacceptable when it ap-
pears on blue 60 pattern.
- Ref. below table
Note: The defect criteria follows TI specication.
4. Dead Pixel (Bright pixel)
Procedure - Test equipment: video generator.
- Test signal: analog 1280 x 720@60Hz.1280 x 720@60Hz..
- Test Pattern: full black
Inspection item - Bright pixel check.
Note: Frame dimension under operative zone1
inch
Criteria - Bright pixel is unacceptable.
- Ref. below table
Note: The defect criteria follows TI specication.
5. Dead Pixel (Dark pixel)
Procedure - Test equipment: video generator.
- Test signal: analog 1280 x 720@60Hz.1280 x 720@60Hz..
- Test Pattern: full white
Inspection item - Dead pixels check.
- White pattern (IRE=100)
- Adjacent dark pixel.
Criteria - The number of the dead pixels should be less or
equal to 6 pixels.
- Adjacent pixel with each other is unacceptable.
- Ref. below table
Note: The defect criteria follows TI specication.
6. Focus test
Procedure - Test equipment: video generator.
- Test signal: analog 1280 x 720@60Hz1280 x 720@60Hz
Full black
Full white
