Acer H5350 - Page 87

H5350
Condential
I
Appendix A
ASSY FAN SHIELDING MODULE WHITE H5350
Item P/N Description Parts Supply
70.89T13GR01
ASSY AXIAL FAN MODULE P5270(RMA)
1 85.1F123G260 SCREW PAN MECH E/SF M3*26 Ni NO
2 49.88T01G001 SUNON, KDE1207PKV1-A 70*70*20mm
AXIAL FAN
NO
3 43.88N01G001 THERMAL SWITCH WITH BRACKET
(KLIXON YS11) 100 DEG. C
1
2
3
