Acorp 6A815E1 - CD-Audio-IN Connector: CN1

1-131-13
1-131-13
1-13
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc CdrbrhoshnnChaosdr 1 Mnshdranarc Cdrbrhoshnn
Chaosdr 1 Mnshdranarc Cdrbrhoshnn
1.7.6 CD Audio-In Connector: CN1
CN1 is the connector for CD-Audio Input signal. Please
connect it to CD-ROM CD-Audio output connector.
These connectors support cooling fans of 1Amp or
less. Orientate the fans so that the heatsink fins allow
airflow to go across the onboard heat sink(s) instead
of the expansion slots. Depending on the fan
manufacturer, the wiring and plug may be different.
The red wire should be positive, while the black should
be ground. Connect the fan’s plug to the board taking
into consideration the polarity of the this connector.
Pin CN1 Definition
1 CD-R
2 GND
3 GND
4 CD-L
USB1
COM1
6A815EP1
not onboard
VGA
AGP1
Speaker out
Line in
MIC in
Printer
IR
FAN1
JP6
FAN3
GAME1
Intel
Intel
PCI SLOT2
PCI SLOT1
PCI SLOT3
PCI SLOT4
PCI SLOT5
CNR SLOT
J7
1
FAN2
JP4
BIOS
I/O CHIP
LAN C HIP
JP7
LED1
VGA
Optional
CN1
