7.6 Buttons
The MINILED has three buttons.
located between the LCD screen and the optical guide used to start up the MINILED and to start or stop the
cure cycle.
used to select the modes.
used to select the exposure time.
7.7 Wave peak
7.5mm-diameter opalescent optical guide
Centre wavelength 455nm - 465nm
Maximum irradiance at 2 mm 2,000mW/cm
2
standard ±10%
7.8 Waveform with micro-flash
Exposure time Waveform (nominal value, irradiance, duration) Average irradiance over time
1 second 2000mW/cm
2
standard
7.9 Mains adapter
The mains adapter is part of the medical device and helps to ensure its electrical safety. It must be installed near the
medical device and must be readily accessible.
The mains cord connects the mains adapter to the medical device
Only use the mains adapter supplied with your medical device.
Page 18/38 - User Manual|MINILED SUPERCHARGED|J02261EN|V2|(09)|08/2018|NG35EN010B
