Acteon MINILED SUPERCHARGED - Battery

Number of LED lights 1
Wavelength range 420nm - 480nm
Centre wavelength 455nm - 465nm
Irradiance with 7.5mm-diameter, 45° curve,
multi-fibre opalescent optical guide
2,000mW/cm²
Irradiance with 5.5 mm-diameter, 45° curve,
multi-fibre opalescent optical guide
3000mW/cm²
Operating mode Continuous
Type B
Safety
Thermal safety of the handpiece - The medical device stops if the
internal temperature of the handpiece reaches 70°C (± 5°C):
l
appears on the LCD screen.
l Four beeps sound.
l The light indicator turns red.
l Leave the handpiece to cool for a few minutes, until the light
indicator turns green and the screen again displays the selected
time cycle.
Ingress protection rating IPX0
11.5 Battery
Type Lithium-ion
Capacity 2500mAh
Output voltage 3.7 V
Charging time 3hours
Life when fully charged 350 cycles of 10s (28days at standby)
Diameter 22 to 24 mm
Length 88 mm
Weight 75 g
11.6 Environmental characteristics
Ambient operating temperature +10°C to +30°C
Operating RH 30% to 75%
Atmospheric operating pressure Between 800 hPa and 1060 hPa
Maximum operating altitude Equal to or less than 2000 metres
Storage temperature 0°C to +50°C
Storage RH 10% to 95%, including condensation
Atmospheric storage pressure Between 500 hPa and 1060 hPa
11.7 Environmental restrictions
Usage premises
Usable in all medical premises. The medical device must not be used
in an operating theatre or outdoors.
Use in gas-filled atmosphere
The medical device is not designed for use in a type AP or APG gas-
filled atmosphere or in the presence of anaesthetic gases.
Page 26/38 - User Manual|MINILED SUPERCHARGED|J02261EN|V2|(09)|08/2018|NG35EN010B
