Operator’s manual • X-Mind trium • V0G • (13) • 10/2017 • NTR0EN040G
ENGLISH
101 C
"HI_VOLT_ENA_IN_IDLE
Inverter board error:
GENERAL STATE ERROR, bit 5 - HV
ENABLE SIGNAL ACTIVE IN IDLE
MODE"
T
"Reset error from workstation; if error remains restart trium
and workstation.
If error remains technical service is required:
check cables between Inverter board and tubehead;
check/replace tubehead;
check/replace Inverter board."
102 C
"PRE_HEAT_NOT_FINISH
Inverter board error:
GENERAL STATE ERROR, bit 6 -
FILAMENT PRE HEATING NOT
COMPLETED"
T
"Reset error from workstation; if error remains restart trium
and workstation.
If error remains technical service is required:
check cables between Inverter board and tubehead;
check/replace tubehead;
check/replace Inverter board."
103 C
"OVER_VOLTAGE_ON_POS
Inverter board error:
GENERAL STATE ERROR, bit 8 -
OVERVOLTAGE ON POSITIVE STAGE"
T
"Reset error from workstation; if error remains restart trium
and workstation.
If error remains technical service is required:
check cables between Inverter board and tubehead;
check/replace tubehead;
check/replace Inverter board."
104 C
"OVER_VOLTAGE_ON_NEG
Inverter board error:
GENERAL STATE ERROR, bit 9 -
OVERVOLTAGE ON NEGATIVE STAGE"
T
"Reset error from workstation; if error remains restart trium
and workstation.
If error remains technical service is required:
check cables between Inverter board and tubehead;
check/replace tubehead;
check/replace Inverter board."
105 C
"OVER_CURRENT_ON_POS
Inverter board error:
GENERAL STATE ERROR, bit 10 -
OVERCURRENT ON POSITIVE STAGE"
T
"Reset error from workstation; if error remains restart trium
and workstation.
If error remains technical service is required:
check cables between Inverter board and tubehead;
check/replace tubehead;
check/replace Inverter board."
106 C
"OVER_CURRENT_ON_NEG
Inverter board error:
GENERAL STATE ERROR, bit 11 -
OVERCURRENT ON NEGATIVE STAGE"
T
"Reset error from workstation; if error remains restart trium
and workstation.
If error remains technical service is required:
check cables between Inverter board and tubehead;
check/replace tubehead;
check/replace Inverter board."
107 C
"VOLT_LOW_LIM_ON_POS
Inverter board error:
GENERAL STATE ERROR, bit 12 -
VOLTAGE TOO LOW ON POSITIVE
STAGE"
T
"Reset error from workstation; if error remains restart trium
and workstation.
If error remains technical service is required:
check cables between Inverter board and tubehead;
check/replace tubehead;
check/replace Inverter board."
108 C
"VOLT_UPP_LIM_ON_POS
Inverter board error:
GENERAL STATE ERROR, bit 13 -
VOLTAGE TOO HIGH ON POSITIVE
STAGE"
T
"Reset error from workstation; if error remains restart trium
and workstation.
If error remains technical service is required:
check cables between Inverter board and tubehead;
check/replace tubehead;
check/replace Inverter board."
109 C
"VOLT_LOW_LIM_ON_NEG
Inverter board error:
GENERAL STATE ERROR, bit 14 -
VOLTAGE TOO LOW ON NEGATIVE
STAGE"
T
"Reset error from workstation; if error remains restart trium
and workstation.
If error remains technical service is required:
check cables between Inverter board and tubehead;
check/replace tubehead;
check/replace Inverter board."
