Operation Manual
CL01-2 Wall Controller
Operation Manual - CL01-2 Wall Controller
Document: 0525-081 Ver. 1 190903
23
CM100 FAULT ERROR CODES
Alarm Code Description Type Alarm Condition Reset Condition
E10
All Other Alarms
(See CP05 or CP10 for details)
Alarm Various Alarms Normal Condition
E11
Probe 1 Fault
(CM100 Internal Error)
Alarm Configuration Error Correct Set up
E12
ID Coil Sensor 1 Fault Alarm Temperature out of Range Temperature Normal
E13
Probe 3 Fault
(CM100 Internal Error)
Alarm Configuration Error Correct Set up
E14
Probe 4 Fault
(CM100 Internal Error)
Alarm Configuration Error Correct Set up
E15
Discharge Temperature 1 /
High Pressure Comp 1 Fault
Alarm
Temperature out of Range
Temperature and
Pressure Normal
Compressor 1 High Pressure
E16
OD Coil Sensor 1 Fault Alarm Temperature out of Range Temperature Normal
E17
Discharge Temperature 2 /
High Pressure Comp 2 Fault
Alarm
Temperature out of Range
Temperature and
Pressure Normal
Compressor 2 High Pressure
E18
OD Coil Sensor 2 Fault Alarm Temperature out of Range Temperature Normal
E19
Probe 9 Fault
(CM100 Internal Error)
Alarm Configuration Error Correct Set up
E20
Outside Air Temperature Sensor
Fault
Warning Temperature out of Range Temperature OK
E21
Multi Input 1 Fault Alarm Input out of Range Input Normal
E22
Multi Input 2 Fault Alarm Input out of Range Input Normal
E23
Outdoor Fan 1 Fault Alarm Not Operating Normal Operation
E24
Outdoor Fan 2 Fault Alarm Not Operating Normal Operation
E25
Indoor Fan Fault Alarm Not Operating Normal Operation
E26
Return Air Temperature Sensor Fault Warning Temperature out of Range Temperature OK
E27
Supply Air Temperature Sensor Fault Warning Temperature out of Range Temperature OK
E28
Indoor Fan Overload Fault Alarm Circuit Breaker Tripped Normal Operation
E29
Compressor 1 Overload Fault Alarm Circuit Breaker Tripped Normal Operation
E30
Compressor 2 Overload Fault Alarm Circuit Breaker Tripped Normal Operation
E31
Compressor 1 LP Fault Alarm Compressor 1 Low Pressure Normal Pressure
E32
Compressor 2 LP Fault Alarm Compressor 2 Low Pressure Normal Pressure
E33
Compressor 3 LP Fault Alarm Compressor 3 Low Pressure Normal Pressure
E34
Compressor 1 HP Fault Alarm Compressor 1 High Pressure Normal Pressure
