14. Alarm Matrix
INDOOR BOARD FAULT ERROR CODES
Alarm Code Description Type Alarm Condition Reset Condition
E1
Auxiliary Sensor Error (OC/SC) Alarm No Sensor, Sensor OC/SC Sensor OK
E2
Indoor Coil Sensor Error (OC/SC) Alarm Coil Sensor OC/SC Sensor OK
E3
Over Current
Alarm
Input out of Range Normal Operation
Under Current Indoor Fan not running Normal Operation
E4
Wrong Dip switch Error Alarm Wrong Dipswitch Settings Correct Settings
E5
Communication Error Alarm
No communication with OD
NOTE:
Wait for 30 sec. before E5 is displayed.
Communication OK
E6
Indoor Fan Fault Alarm Not Operating Normal Operation
E7
0-10VDC No Input Alarm
Input is less than 0.1V when 3rd Party
voltage control is selected on ID
Correct 0-10VDC Input
E8
Reserved for Other Errors Alarm --- ---
E9
Reserved for Other Errors Alarm --- ---
