- 13 -
The chart below details a common array of sources typically connected to the SSD-66 (5.1).
It also indicates the types of jacks these components may include on their rear panels. In the
case of recording devices such as VCRs and Cassettes, make certain that you are using the
jacks marked "Output".
Now that you have gotten a source profile for your system, number no more than six sources
with the numbers 1-6 in the far left column, starting at the top with number 1 and going down.
These will be the six sources connected to your SSD-66 (5.1) and you can now proceed with
the instructions on page 14. If you have more than six sources and require additional input
switching continue with the following page.
SOURCE NAME VIDEO OUTPUT
ANALOG AUDIO
OUTPUT
AC-3 DIGITAL RF
OUTPUT (RCA)
DIGITAL COAX
(RCA) AUDIO
OUTPUT
DIGITAL OPTICAL
(TOS-LINK) AUDIO
OUTPUT
AC-3/DTS LASER DISC PLAYER X X MAY HAVE MAY HAVE MAY HAVE
TV TUNER OR CABLE BOX X X
VCR X X
SATELLITE X X MAY HAVE
DSS X X MAY HAVE
DVD XXXX
CAMCORDER X X
CD X X MAY HAVE MAY HAVE
RADIO TUNER X
CASSETTE X
MULTI-ROOM SYSTEM X MAY HAVE
For Your System
At this time, it is suggested that you proceed to fill in the chart below marking the boxes with
an "X" if they pertain to your particular source components. An additional six lines have been
added as blanks for sources which you may have that are simply not listed below. Again, it is
stressed to visually inspect the source components to make certain that the various outputs
actually do exist or do not exist on your sources.
SOURCES TO INCLUD
ON SSD-66 (5.1) -
NUMBER 1 THROUGH
SOURCE NAME VIDEO OUTPUT
ANALOG AUDIO
OUTPUT
AC-3 DIGITAL RF
OUTPUT (RCA)
DIGITAL COAX
(RCA) AUDIO
OUTPUT
DIGITAL OPTICAL
(TOS-LINK) AUDIO
OUTPUT
AC-3/DTS LASER DISC PLAYER
TV TUNER OR CABLE BOX
VCR
SATELLITE
DVD
CAMCORDER
CD
RADIO TUNER
CASSETTE
MULTI-ROOM SYSTEM
To Next Page
