ADB PHOENIX User Manual

Page 6
Rev. : 002
HF - VISION 10 & PHOENIX
Lighting Technologies
4. Installation
4.1. Hardware
There are two different installation types:
1. single receiver - one ore more transmitters; operating range 50-80m
2. up to 4 receivers - one ore more transmitters; operating range >50-80m
4.1.1. Components
The HF remote control unit comprises the following items:
Simple Point-To-Point Communication (50 - 80m)
item code adb code number
Transmitter 734A EMHF/V 6382,01,400
SAT Receiver RS232 REHF1/V 6382,01,410
containing:
- ext. 9V psu
- RS232 cable RJ45-DB25, 6m
- DB25/DB9 adapter
- wall mounting kit
Battery Charger BCHF/V 6172,30,030
containing:
- ext. 9V psu
Multiple Communication (up to 4 receivers; >50 - 80m)
item code adb code number
Transmitter 734A EMHF/V 6382,01,400
SAT Receiver RS485 REHF2/V 6382,01,420
containing:
- ext. 9V psu
- t-connector box
- RS485 cable T-box - SAT, 6m
- wall mounting kit
Converter RS485/RS232 CONHF/V 6382,01,430
containing:
- ext. 9V psu
- RS232 cable RJ45-DB9, 2m
- T-BOX + cable to converter
- cable from T-box to converter,2m
Battery Charger BCHF/V 6172,30,030
- ext. 9V psu
Further needed:
item code adb code number
PC with two com ports PC1/V 6382,01,440
Windows NT WIN/NT 2820,00,200
Common Options
item code adb code number
Leather Holster LHHF/V 6382,01,470
Battery kit (4 p. rechargeable) BKHF/V 6172,30,020
Sysnet cable (per meter) CAHF/V 6104,01,010
