11
2.
Cycle in Progress Display Status
a. Automatic Drying Cycle (Mode) (Patent No. 4,827,627) - the light emitting diode (L.E.D.) display
reads Percentage of Extraction in the cycle in progress and then Cool Down.
b. Timed (Manual) Cycle (Mode) - the L.E.D. display reads Drying Time and/or Cool Down Time counting
downwards as time elapses.
3.
Indicator Dots on the L.E.D. Display
a. The indicator dots are an indicator as to the various Phase 6 OPL microprocessor controller (computer)
output functions. Additionally, there are also indicators on the back side of the Phase 6 OPL
microprocessor controller (computer) to verify the outputs of the relay.
1) Drive Motor (blower motor on reversing models).
2) Heat On (active).
3) Reversing models have indicators for the forward (clockwise [CW]) basket (tumbler) rotation and
reverse (counterclockwise [CCW]) basket (tumbler) rotation.
H. CYCLE IN PROGRESS TEMPERATURE DISPLAY
While the dryer cycle is in progress, the temperature in the basket (tumbler) can be displayed by pressing the
“ENTER/START” Key. The temperature will be displayed in either Fahrenheit (ºF) or Celsius (ºC), depending
on how the temperature conversion status program is set.
I. TEMPERATURE CONVERSION STATUS
Temperature related programs are programmable to be operated in either Fahrenheit (ºF) or Celsius (ºC). Programs
affected are:
1. Temperature Display Mode
2. Temperature Selections (drying temperatures)
3. Cool Down Temperatures
IMPORTANT: When changing the temperature conversion status from Fahrenheit or Celsius or vice
versa, ALL the Temperature Selections and Cool Down Temperatures will be
changed accordingly. The Phase 6 OPL microprocessor controller (computer)
automatically calculates and converts the temperatures in these programs to the
previously set value. For example, when changing from ºF to ºC, if the
preprogrammed Cycle “A” drying temperature was set for 160º F, the Phase 6 OPL
microprocessor controller (computer) will change to 71º C (+/- [1] one-degree
Celsius).
