26
SECTION VI
PROGRAMMING INSTRUCTIONS
A. INTRODUCTION TO PROGRAMMING
The various program selections are stored in the Phase 6 OPL microprocessor controller (computer) and are
broken down into two (2) categories:
1.
Preprogrammed Cycles (Key “A” through Key “F”)
a. Allow the operator to have six (6) most commonly used cycle selections awaiting the push of a single
keyboard (touch pad) entry to start the dryer.
2. System Parameters
a. Which are the programs set by the factory and rarely need to be changed in the field. These system
parameters (programs) are stored in the memory as Program Locations (Key “2,” Key “5,” Key “8,”
and Key “0”).
Both the preprogrammed cycles and the system parameters (programs) have been preprogrammed by the
factory with the parameters shown on page 51 and page 52 of this manual. The various program selections for
the preprogrammed cycles and system parameters are outlined in Section III of this manual.
ALL the program changes for the preprogrammed cycles and system parameters (programs) are done through
the keyboard (touch pad) selection keys on the front of the control panel. To change programs, an access code
must be entered. The procedure for entering this access code as follows:
First, make sure that no cycle is in progress and that the light emitting diode (L.E.D.) display reads “REAdY.”
Then press the “ENTER/START” Key ONCE and the “0” Key three (3) times. The “0” Key
must be pressed three (3) times within 2-seconds after pressing the “ENTER/START” Key. If
this access sequence is not entered correctly, the Phase 6 OPL microprocessor controller (computer)
will deny access into the Program Mode. If the access code is entered correctly, the L.E.D. display will
read “PROGRM.” From this point, any of the preprogrammed cycles or system parameters (programs) can be
accessed.
To alter the programming the operator will locate the parameter (program) that is to be changed. If the change
is a numerical one (i.e., time and/or temperature), the operator will simply enter the numerical value desired. If
an error is made, press the “CLEAR/STOP” Key ONCE, and the incorrect entry that was made will be
cancelled. Once the entry is made, or the parameter (program) set does not need to be changed, press the
“ENTER/START” Key, and the Phase 6 OPL microprocessor controller (computer) will advance to the next
program selected.
If the parameter (program) change is a status change, such as changing the temperature conversion from
degree Fahrenheit (ºF) to degree Celsius (ºC) or from “AUTO” (Automatic Drying Cycle - Patent No.
(4,827,627) to “MANUAL” (Timed [Manual] Drying Cycle), the operator will press the “0” Key ONCE. The
“0” Key acts as a flip-flop switch to change the programming of a parameter. Once the entry is made, or if the
parameter (program) set does not need to be changed, press the “ENTER/START” Key, and the Phase 6
OPL microprocessor controller (computer) will advance to the next program selection.
