Fault Codes
bURNER CONTROL FAIL
- GAS MODELS ONLY ... POWER (24 VAC) is NOT EVIDENT at GAS VALVE
bURNER FLAME FAIL
- the Phase 6 Microprocessor Controller (computer) DOES NOT SENSE FLAME VERIFICATION
(GAS MODELS ONLY)
bURNER SAFETY FAIL
- GAS/ELECTRIC ONLY ... BURNER/OVEN OPEN HI-LIMIT CIRCUIT
dRUM SAFETY FAIL
- fault in the TUMBLER HI-LIMIT CIRCUIT
HOT
- indicates an OVERHEAT CONDITION
LINT dOOR
- when the LINT DOOR or LINT DRAWER is open or there is a fault in the LINT DOOR/DRAWER
CIRCUIT
MAIN dOOR
- when the MAIN DOOR is open or there is a fault in the DOOR CIRCUIT
No AIRFLOW
- fault in the SAIL SWITCH CIRCUIT (GAS/ELECTRIC MODELS ONLY)
No HEAT
- GAS ONLY ... IGNITION ATTEMPT FAILURE
ROTATE SENSOR FAIL
- fault in the ROTATION SENSOR CIRCUIT
SAIL SWITCH FAIL
- fault in the SAIL SWITCH CIRCUIT (GAS/ELECTRIC MODELS ONLY)
TEMP SENSOR CHECK TEMP SENSOR FUSE
- fault in the MICROPROCESSOR TEMPERATURE SENSOR CIRCUIT
