SECTION VII
FACTORY PRESET PARAMETERS/PROGRAMS
A. PARAMETERS (PROGRAMS) PRESET BY FACTORY
FOR NON-REVERSING DRYERS
CYCLE A:
Automatic Mode, Anti-Wrinkle Active, Dry Temperature 180º F, Dryness Level 100%, Cool Down Time 6
minutes, Cool Down Temperature 80º F, A Factor, b Factor.
CYCLE B:
Automatic Mode, Anti-Wrinkle Active, Dry Temperature 180º F, Dryness Level 98% Cool Down Time 6
minutes, Cool Down Temperature 80º F, A Factor, b Factor.
CYCLE C:
Automatic Mode, Anti-Wrinkle Active, Dry Temperature 160º F, Dryness Level 98%, Cool Down Time 4
minutes, Cool Down Temperature 80º F, A Factor, b Factor.
CYCLE D:
Manual (Timed) Mode, Anti-Wrinkle Active, Dry Time 40 minutes, Dry Temperature 190º F, Cool Down
Time 6 minutes, Cool Down Temperature 80º F.
CYCLE E:
Manual (Timed) Mode, Anti-Wrinkle Active, Dry Time 30 minutes, Dry Temperature 180º F, Cool Down
Time 4 minutes, Cool Down temperature 80º F.
CYCLE F:
Manual (Timed) Mode, Anti-Wrinkle Active, Dry Time 10 minutes, Dry Temperature 170º F, Cool Down
Time 2 minutes, Cool Down Temperature 80º F.
SYSTEM PARAMETERS/PROGRAMS
Program Location 2 - (Key “2”) Specific Heat selection (GAS, STEAM, ELECTRIC), Temperature Conversion
Status (set in Fahrenheit), Rotational Sensor (non-active), Factor “A” and
Factor “b” (set for your particular model dryer and should not be changed).
Program Location 5 - (Key “5”) NFlash - Drying Auto Cycle A, B, or C
Elapse Time _ _ Min
NFlash - Drying Manual Cycle D, E, or F
_ _ Min Remain
Flash - Drying Auto Cycle A, B, or C
Elapse Time _ _ Min
Drum Temp º F or º C
Flash - Drying Manual Cycle D, E, or F
_ _ Min Remain
Drum Temp º F or º C
Program Location 8 - (Key “8”) Timed (Manual) (Automatic) drying mode Cool Time 6 Minutes, Cool
Temperature 80º F, Buz (Tone) Time 7-seconds.
