ADC PHASE 6 OPL - Operating Sequence: Manually Loaded Cycles

19
7) If the Anti-Wrinkle Program is active (on), once the drying cycle and cooling cycles are completed
and the light emitting diode (L.E.D) display reads “dONE,” the Phase 6 OPL microprocessor
controller (computer) will proceed into the Anti-Wrinkle Program, L.E.D. displays “START GUARd.”
If the main door
is not opened within the Anti-Wrinkle Delay Time (i.e., 90-seconds), the basket
(tumbler) will rotate (without heat) for the programmed Anti-Wrinkle On Time (i.e., 20-seconds).
The Phase 6 OPL microprocessor controller (computer) will repeat this process until the programmed
Maximum Anti-Wrinkle On Time has expired (i.e., 10 minutes). The L.E.D. display will read
“dONE,” until the main door is opened.
2.
Manually Loaded Cycles
a.
Automatic Drying Cycle (Patent No. 4,827,627)
1) L.E.D. display reads “REAdY” (no cycle in progress).
2) Press Auto Key.
3) L.E.D. display will now read dRY TEM PF___ Fabric (temperature) desired. Enter the temperature
desired (from 160º F to 200º F in one-degree increments or from 71º C to 93º C in one-degree
increments). For example, for F180, press Key “1,” Key “8,” Key “0,” and then press the “ENTER/
START” Key.
4) L.E.D. display will now read dRY LEVEL___ enter the percentage of extraction (dryness level
desired) (from 90% to 100% in one-percent increments). For example, for 95%, press Key “9,”
Key “5,” and then press the “ENTER/START” Key.
5) For optional reversing models, if the system parameters are set for Select Reverse, the L.E.D.
display will now read “SEL REV” meaning “Select Reverse.” If reversing basket (tumbler) action
is desired, press the “ENTER/START” Key. If No Reverse is desired, press the “0” Key.
6) The dryer will now display “PRESS START” press the “ENTER/START” Key to start the
dryer. The L.E.D. display will read dRYING AUTO CYCLE, ELAPSE TIME__MIN, dRUM
TEMP___F. (FLASH [PL5] must be active for the “dRUM TEMP” to display. If NFLASH is
active then press “ENTER/START” Key to display “dRUM TEMP.”) During the Drying Cycle,
the Phase 6 OPL microprocessor controller (computer) in monitoring the moisture in the load.
Approximately half way through the drying cycle, the Cycle Status portion of the L.E.D. will display
(i.e. dRY LEVEL 68PcT). The display will change and count upward until the percentage of
extraction programmed is reached.
NOTE: To stop the dryer at any time, open the main door. To continue the cycle, close the main door,
the Phase 6 OPL microprocessor controller (computer) prompts the operator “PRESS
START” then press the “ENTER/START” Key. The dryer will continue from where it left
off, or ... the dryer may also be stopped by pressing the “CLEAR/STOP” Key. However,
the cycle that was in progress will be cancelled, and the L.E.D. display will return to the
“REAdY” (no cycle in progress) Mode.
