ADC PHASE 6 OPL - SYSTEM PARAMETERS (Program Locations;Review)

14
O. SYSTEM PARAMETERS (PROGRAM LOCATIONS/REVIEW)
The system parameters are the programs which, once set by the factory, rarely need to be changed in the field.
These system parameters (programs) are stored in the memory and catalogued as program locations (Keys “2,”
“5,” “8,” and “0”).
ALL of the parameters affect the manually loaded program cycles, and some affect the preprogrammed cycles.
The information on page 53 shows the parameters of each program location, as well as what cycles are
affected. The programming limits of each program location are shown on
page 54 and page 55. Additionally,
the parameters preset by the factory are shown on page 51 and page 52.
Review system parameters (programs) with one touch of the keyboard (touch pad) (Key “8”). The Phase 6
microprocessor controller (computer) will automatically display Program Locations “2,” “5,” “8,” and “0.”
1. Program Location 2 (Key 2)
a.
Dryer Operation “Specific Heat Selection” - this program controls which heat source will be used in the
program. The program will be operated in either “GAS,” “STEAM,” or “ELECTRIC,” depending on
the heat service applied to the dryer.
b.
Temperature Conversion Status - this program controls whether the temperature-related programs will
be operated in Fahrenheit (ºF) or Celsius (ºC). The programs affected are as follows:
1) Temperature Display Mode.
2) Temperature Selections (drying temperatures).
3) Cool Down Temperatures.
IMPORTANT: The Phase 6 OPL microprocessor controller (computer) automatically calculates and
converts the temperatures in these programs to the previously set value. For example,
when changing from º F to º C, if the preprogrammed Cycle “A” drying temperature
was set for 160º F, the Phase 6 OPL microprocessor controller (computer) will
change to 71º C (+/- one-degree Celsius).
c. Select Reverse - for optional reversing models, this program allows the operator to have a choice of
Reverse or No Reverse (single direction rotation) basket (tumbler) action in the manually loaded cycles
ONLY.
1) Always Reverse (ALL REV) - in this operational mode the operator has no choice. Any manually
loaded cycle entered will be a reversing cycle.
2) Select Reverse (SEL REV) - when this parameter (program) is chosen, the Phase 6 OPL
microprocessor controller (computer) will prompt the operator to decide whether or not the manually
loaded cycle entered is to be a reversing cycle.
