57
* “A” and “B” Factors
NOT AVAILABLE at time of printing.
(A) For
60 Hz models ONLY.
(B) For 50 Hz models ONLY.
(C) For models manufactured with optional Heat Reclaimer (HR) ONLY.
(D) For models manufactured with a 7.5 HP blower (fan) motor.
(E) For models manufactured with a 15 HP blower (fan) motor.
IMPORTANT: The “A” and “B” Factors have been preprogrammed by the factory and should not
be changed in the field unless the Phase 6 OPL microprocessor controller (computer)
should fail and is being replaced. THE REPLACEMENT PHASE 6 OPL
MICROPROCESSOR CONTROLLER (COMPUTER) MUST BE
REPROGRAMMED FOR THE SPECIFIC MODEL SHOWN IN THE “A” and
“B” FACTOR PARAMETERS CHART ON THE PREVIOUS PAGE (page 56).
The “A” “B” FACTOR LABEL IS LOCATED IN THE TOP CONTROL PANEL,
BEHIND THE PHASE 6 KEYBOARD (TOUCH PAD) - DISPLAY DOOR.
