9
Table 6 Electrical Specification (only for ADT673)
Current Measurement
±30.0000mA; Accuracy: ±(0.01%RD+0.005%FS); Resolution:0.0001mA; Input impedance: 25Ω.
Voltage
Measurement
±30.0000V; Accuracy: ±(0.01%RD+0.005%FS); Resolution:0.0001V; Input impedance <1MΩ.
Switch Test
Mechanical, NPN and PNP type supported.
Output
Internal loop power: 24V±1V, maximum output circuit: 30mA.
Display
Circular TFT LCD capacitive touch screen
Power supply
1. 6600mAh Lithium-ion rechargeable battery, power consumption around 2.5W
2. Special TYPE-C USB adapter for power supply, maximum charging current 2A (battery power for best
accuracy);
Charging
Charging time is about 5 hours, provided by dedicated 5V adapter
Battery life
24V power supply loading will affect the battery life.
Dimension
175mm×118mm×41mm
Weight
715g
Electrical Connections
Circuit, voltage and switches
：
standard φ4mm
；
DC24Voutput
：
standard φ4mm
；
Charging
：
standard TYPE-C USB connection
