in manually:
Table 15 Wireless communication manually setting
Item
Effective value
Description
IP Address
0.0.0.0 ～ 255.255.255.255
Set IP address of device
Subnet mask
0.0.0.0 ～ 255.255.255.255
Set subnet mask of device
Gateway
0.0.0.0 ～ 255.255.255.255
Set gateway of device
(1) Click the button at the bottom right corner of the screen to confirm the settings.
(2) The wireless communication settings take effect directly without confirming the operation. Click button
in the upper right corner of the screen to return to the previous menu.
3.1.3 Serial Communication
This setting is provided when the optional module is an RS232 module, and the device can communicate through
the serial port at this time.
Table 16 Serial port communication
Item
Effective value
Description
Baud rate
2400/4800/9600/19200/38400/57600/115200/256000
Factory default is 9600
Date length
7/8
Factory default is 8
Stop bit
1/2
Factory default is 1
Odd-Even check
None/Odd/Even
Factory default is None
