42
4 . Task (ADT673 only)
In the function menu page, click to enter task page. The calibrator provides test task function, which makes it
possible to document calibrations, collect, store and analysis calibration data, and makes it easier to re-perform and
review.
4.1 Calibrate Dial Pressure Gauge
1. Connection
(1) Refer to Figure 12, connect the calibrator with the dial pressure gauge;
Figure 12 Calibrate Dial Pressure Gauge
(2) If the gauge is differential gauge, it is recommended to connect the REF port.
2. Set a new task
