5 . Data log
Click on the button in the function menu page to enter the data log management. The calibrator supports the
continuous data log, which can continuously record the measured signal data within the set time. Both the electrical
signal and the pressure value are recorded simultaneously.
Click on the recorded data to view it, and select to view the curve, detailed data, export, and delete.
1. New test
(1) Before recording, click on and to zero the pressure module;
(2) The bottom of the screen shows reading value of the current controlled pressure, and the top is the switch
status;
(3) Switch action status and action value will be recorded and displayed in the table;
(4) Click on the Stop icon to close the running task and view the result;
(5) Click on at the bottom of the screen to confirm and the task starts automatically, click on to quit this
task;
(6) In the task, click on to stop the record, confirm Stop by clicking on when asking whether to stop, and
the data will be saved automatically.
Table 24 Information for Data log
Letters, numbers, symbols, Chinese
characters
