Additel 686 - 6 Data Management

51
Operator
Letters, numbers, symbols, Chinese
characters
Information for data log operator
Record interval
Number
Data record interval
Record point
Number
Total amount of data record points
Record date
2000/01/01~2099/12/31
Data record date
Pressure unit
Pressure unit
Type of the recorded pressure unit
Pressure type
Gauge pressure, absolute pressure
The type of calibrated switch, view support information according
to calibrator’s model
Electrical
measurement
(-30~30)mA, (-30~30)V, switch, HART
Mode of recording the electrical measurement
2. Edit the page
When there are series of pages, switch the page number one time through , or click on Edit Page icon
to jump pages.
3. Delete mode
When you need to delete data, click on the delete mode in the menu. Select the item to be deleted with a
check icon √, then delete to proceed. If you need to jump page, do the same as 2.
6 . Data management
Click on in the function menu to enter the data management page.
It is classified and managed by functional modes; the data saved in each function is managed in the corresponding
items;
The function modes that can save data files include: snapshot, pressure leak test, etc;
