For some of the parameters, enter the page and click on at the right of the screen to view the instruction
information.
Click on the and at the right of the screen to view the communicate status and device status respectively.
Enter it and the vacant circle on the right of the list indicates that it is normal, otherwise it means that the item is
abnormal.
Click on at the right of the screen to return to the home page of the device and click on at the right top of
the screen to return to HART communicator again.
9 .Copyright
Additel corporation owns all copyrights to this system and reserves all rights.
Appendix A：Description of RS232 module DB9 pins
