3-CH WS2812 RGB LED-B
At this point, all the 3-CH WS2812 RGB LEDs are left with only one end of the
3-Pin Wires -B connected to the 3-CH WS2812 RGB LED-B unconnected. We
leave it at the end and connect with the Adeept Motor HAT.
After assembly, connect the wire at the input of
3-CH WS2812 RGB LED-A (which has been
pierced from the square hole on A01) to the
output of the 3-CH WS2812 RGB LED-A marked
with a red circle.
