ADEEPT PiCar-B - Chassis and Battery Holder Assembly

www.adeept.com
9
Effect diagram after assembling
2.2. Car Light and Battery Holder Assembly
1. Fix two M3*12 Copper Standoff on A01.
Assemble the following components
M3*12 Copper Standoff is fixed on the
marked side of A01
A01 x1
M3*12 Copper
Standoff x2
M3*8 Screw
x2
