46
Effect diagram after assembling
Finally turn the upper part of the servo back to original position.
2.6. Raspberry Pi assembly
1. Fix M2.5*10+6 Copper Standoff and M2.5*14 Copper StandofftoRaspberryPi.
M2.5*14 Copper
Standoff X1
Effect diagram after assembling
Assemble the following components
M2.5*10+6 Copper
Standoff X1
