2.5. Front part assembly
1. Fix Raspberry Pi Camera to A18.
2. Fix the Adeept Ultrasonic Module to the A18.
Assemble the following components
M2 Nut X4
A18 X1
M1.4*6 Self-tapping
Screw X4
Raspberry Pi
Camera X1
Effect diagram after assembling
M2 Nut X4
Assemble the following components
Adeept
Ultrasonic
M1.4*6 Self-tapping
Screw X4
Effect diagram after assembling
