MX2800 M13 Multiplexer User Manual Transaction Language 1 (TL1), Section 9
61200290L1-1G 9-21
DS3CVTHRS ENUM One of the following:
• Disable
•1E3
•1E4
•1E5
•1E6
Indicates a limit on the number of code viola-
tions accepted by the unit over the DS3
before the unit switches controller cards
• 1E3 - 1 out of every 1,000 bits contains a
CV
• 1E4 - 1 out of every 10,000 bits contains a
CV
• 1E5 - 1 out of every 100,000 bits contains
a CV
• 1E6 - 1 out of every 1,000,000 bits
contains a CV
DS3LOFRLY Y/N Y or [N] Identifies status of DS3 LOF alarm relay
• Yes (Y) - enables alarm
• No (N) - disables alarm
DS3LOSRLY Y/N Y or [N] Identifies status of DS3 LOS alarm relay
• Yes (Y) - enables alarm
• No (N) - disables alarm
DS3MAXNUMSW INT 0, 1, 2, ..., N Maximum number of times per hour the unit
is allowed to switch between controller cards.
If number is exceeded, the unit will issue a
trap
DS3MINSWPERIOD INT 0, 1, 2, ..., N Number of seconds that must pass after a
protection switch before another protection
switch will be allowed
DS3PROT Y/N Y or [N] Identifies status of DS3 protection switching
• Yes (Y) - enables DS3 protection switching
• No (N) - disables DS3 protection switching
DS3RAIRLY Y/N Y or [N] Identifies status of DS3 RAI alarm relay
• Yes (Y) - enables alarm
• No (N) - disables alarm
DS3TLOSRLY Y/N Y or [N] Identifies status of DS3 TLOS alarm relay
Yes (Y) - enables alarm
No (N) - disables alarm
DS3XCVRLY Y/N Y or [N] Identifies status of DS3 XCV alarm relay
• Yes (Y) - enables alarm
• No (N) - disables alarm
Table 9-6. TL1 Editing Data Dictionary for DS3 (Continued)
Keyword Type Domain Description
