9-22 61200290L1-1G
Section 9, Transaction Language 1 (TL1) MX2800 M13 Multiplexer User Manual
FMT ENUM One of the following:
•CBIT
•M13
Sets framing format to match the format of
the receive signal at the network interface
• The framing format s set to CBIT
• The framing format is set to M13
LINELEN ENUM One of the following:
•LONG
•SHORT
Identifies Network DS3 line length
• LONG - exceeds 50 feet.
• SHORT - less than 50 feet.
RMTLPBK ENUM One of the following:
•DISABLE
•EITHER
•FEAC
•CBIT
Indicates whether the unit will respond to
remote loopbacks over FEAC, CBIT,
EITHER, or if remote loopbacks are disabled
• DISABLE - do not respond
• EITHER - respond over either FEAC or
CBIT
• FEAC - respond over FEAC
• CBIT - respond over CBIT
SYSCARDARLY Y/N Y or [N] Identifies status of System Controller Card A
alarm relay
• Yes (Y) - enables alarm
• No (N) - disables alarm
SYSCARDBRLY Y/N Y or [N] Identifies status of System Controller Card B
alarm relay
• Yes (Y) - enables alarm
• No (N) - disables alarm
SYSCARDCOMMRLY Y/N Y or [N] Identifies status of System Communication
Fail alarm relay
• Yes (Y) - enables alarm
• No (N) - disables alarm
SYSCARDRLY Y/N Y or [N] Identifies status of System Controller Card
alarm relay
• Yes (Y) - enables alarm
• No (N) - disables alarm
TMG ENUM One of the following:
•LPD
•INT
Identifies timing supply for the DS3
• LPD - loop timed
• INT - internal timing source
Table 9-6. TL1 Editing Data Dictionary for DS3 (Continued)
Keyword Type Domain Description
