Advanced Electronics Mx-5000 Series - Menu Functions

Page 19 of 42
3.8 Menu Functions
The following Menu Functions are available at Level 2. The display shows the primary Level 2 Menu
and the Level 2 User as follows:
[Level 2 Menu] User 1 Node 1
VIEW DISABLE ENABLE
TEST DELAY TOOLS
STATUS
The following table gives a list of the Level 2 Menu Functions, the sub-functions available within
each main function and a brief description for each function.
Main Menu Option Sub Menus Comments
Fires View Zones and Inputs that are reporting a fire alarm condition.
Faults View Zones and Inputs that are reporting a fault condition.
Alarms View Zones and Inputs that are reporting an alarm condition.
Disabled View Zones, Inputs and Outputs that are disabled.
Inputs View the current state of Inputs.
Outputs View the current operational condition of all output circuits / devices.
Log View the Event Log / Alarm Counter
Panel View the operational state, voltage and current loading of the panel input and
output circuits.
Network View Network diagnostics
Warnings View Zones and Inputs that are reporting a warning condition
VIEW
Supervisory View Zones and Inputs that are reporting a supervisory condition
Zone / Inputs
2
Disable a complete zone or an individual input.
Outputs
2
Disable sounder outputs or other devices.
Controls
3
Cancel Level 2 access.
User ID
3
Return Level 2 access to the default User 1
DISABLE
Groups Disable a user-defined disablement group
Zone / Inputs Enable a complete zone or an individual input.
Outputs Enable sounder outputs or other devices.
Groups Enable a user-defined disablement group
ENABLE
Remote Permits remote access controls
Zones
2
Configure one or more zones for walk test.
Display Test the Graphics Display, Status Indicators and Keyboard.
Buzzer Test the Internal Buzzer
Printer Test the connection to the Printer
TEST
Outputs Test Output Devices
DELAY
-- Turn ON / OFF Investigation delays
COMMISSION Enter the Level 3 Commissioning and Panel Programming Functions
Inputs Print the status of inputs
Ouputs Print the status of outputs
Faults Print the fault conditions
Disabled Print the disabled conditions
Log Print the Event Log. (All Events of Fire Only Events Selectable).
Feed Paper Advance the paper in the printer
PRINT
Set-up
2
Configure the printer connection and automatic print options
TOOLS
CHANGE TIME
2
Allows authorised level 2 users to change time.
2
This option can be configured per Level 2 User ID. User 1 does not have permission to change these options.
3
Not required if a key switch is fitted to change access levels.
