3.9.7.3 Network Hardware
The Network Hardware Option provides a diagnostic readout of the operational condition and
readings for the internal panel electronic circuits of other nodes / panels on the network. When the
option is selected, the display shows a list of the nodes indexed by their assigned zone number. For
example:
[HARDWARE] More>
Zone Location
1700 Ground Floor Panel
1701→ Reception Panel
1702→ First Floor Panel
1703→ Second Floor Panel
Press the ÏÐ buttons to scroll through the panels to highlight the required panel.
Press the Î button to view the individual circuit information for the panel selected. The information
includes the circuit text and current value as per the local hardware option. Press the ÏÐ buttons to
scroll through the circuits on the selected panel. Additionally, the sector, node, circuit number and
address information are also available.
3.9.8 View - Log
After selecting to view the log option the display presents a pop-up window to allow selection
between a view of all of the event history, a view of only the fire alarms that have occurred or a view
of the fire alarm counter.
ALL EVENTS .
FIRE EVENTS ONLY
ALARM COUNTER
Press the ÏÐ buttons to highlight the required menu option and then press the button to select it.
The display then shows the appropriate list of events.
3.9.8.1 Event Log
The display will always show the most recent event to have occurred, e.g.
[View Fire Events] Entry 0076
Time/Date Node Lp:Addr Zone
10:54:23 1 1:001.0 001
14/03/06 FIRE ALARM 64
BASEMENT
ROOM 10
< Number of Highlighted Event
< Time, Origin and Zone
< Date, Event and Analogue Value
< Zone Text Description
< Device Location Description
In the above example, the latest fire occurred (Event No. 76) at 10:54 am on March 14, 2006. This
fire alarm originated at the device at address 001(Addr) on Loop 1 (Lp) on Panel No. 1 (Panel). The
device was in Zone 001. The analogue value registered by the device (64) has also been recorded.
The lower two lines show the zone and device location texts descriptions for ease of identification.
Press the ÏÐ buttons to scroll through the fire alarm events logged in the system. Press the Ï
button to show more recent events and press the Ð button to show earlier events.
To view the details for a specific Log Entry Number, it is possible to select the record by typing in the
required number using the number keys.
Press the button to confirm. The display will then display the required record.
Press the ‘Esc’ button to return to the main view menu.
