9. Return the cleaned solenoid plunger, including spring, retainer and
any washers, to the solenoid body. Secure the retainer and remove
the chamber cleaner.
36
Advanced
®
Micro-Osmometer Model 3320 User’s Guide
Solenoid Plunger
Screws
Solenoid Body
Solenoid Retainer
Figure 10: Solenoid Assembly
Washer
Spring Retainer
Spring
Impactor
Figure 11: Solenoid Plunger
