pany name, model number, serial number, firmware version,
machine state, incremental test counter, (65,535 maximum),
NVRAM battery status, block bin value, sample bin value, and
plateau mode in use.
Machine state: 0=Power-up, 1=Setting Changes Saved, 2=Standby,
3=Exit Standby, 4=Start Calibration, 5=Calibration Complete,
6=Start Test, 7=Stop Test.
Example: S|20120510|112632|Advanced Instruments Inc.|3320|
03090845A|3.0|0|2364|1|6|5|1 <CR> <LF>
• Message Type: RESULT
The RESULT message is issued at the end of each successful stan-
dard test. Calibration and Bin tests are not included, and do not have
a corresponding message type.
The message is initiated using the uppercase letter ‘R’, contains a
delimiter between each segment, and is terminated with CR/LF. The
contents of the message include the message type, date, time, com-
pany name, model number, serial number, sample ID if any, result,
and units of measure.
Example: R|20120510|112632|Advanced Instruments Inc.|3320|
03090845A|0123456789ABCDEFGHIJ|2000|mOsm/kg <CR> <LF>
• Message Type: CALIBRATION
The CALIBRATION message is issued during the power-up
sequence after the STATUS message, upon exit from instrument
setup if any changes have been saved, at the start of calibration, and
at the end of calibration after the operator accepts calibration.
The message is initiated using the uppercase letter ‘C’, contains a
delimiter between each segment, and is terminated with CR/LF. The
contents of the message include the message type, date, time, com-
pany name, model number, serial number, last calibration date, last
calibration time, calibration OK/not OK, high point calibration
ON/OFF, and high point calibration OK/not OK.
65
Laboratory Information Management System (LIMS) Interface
