4 Drive
f Read and follow chapter "Chain drive" if your e-bike has
a chain.
f In addition, read and follow the chapter "E-drive" and
the manufacturer's instructions for the e-drive.
or
f Read and follow chapter "Belt drive" if your e-bike has a
belt.
f In addition, read and follow the chapter "E-drive" and
the manufacturer's instructions for the e-drive.
4.1 Chain drive
The chain runs over two toothed gears (front toot-
hed gear = chain ring; rear toothed gear = sprocket).
A chain can be opened, closed again and extended.
3 1 2
Abb.: 3 Chain drive components
1. Chain
2. Chain ring
3. Sprocket
(model-dependent number)
