18
Drive
ORIGINAL INSTRUCTIONS | ADVANCED | 01.2022 | 1002021-01
f Grease the chain with universal oil:
– after you have cleaned the chain,
– if the chain has become (excessively) wet,
– regularly about every 15 operating hours.
f Ensure that the components of the chain drive are
undamaged.
f In case of more stubborn dirt or damage to the chain
drive, consult a bicycle dealer.
4.2 Belt drive
The belt runs over the front and rear pulley.
A belt cannot be opened and closed again and can-
not be extended or shortened.
3 1 2
Abb.: 5 Components of the belt drive
1. Belt
2. Front pulley
3. Rear pulley
f When handling the belt, observe the following note and
associated pictograms to avoid damage to the belt/
loss of function of the belt drive.
