20
Drive
ORIGINAL INSTRUCTIONS | ADVANCED | 01.2022 | 1002021-01
4.2.1 Wear and maintenance
Worn cams on the pulleys can damage the belt. The belt is
also guided less reliably over the pulleys and can slip off.
If the cams on the belt are worn, damaged or torn, the belt
is less reliably guided over the pulleys and can easily slip off
or "jump over". A worn belt can tear.
f Check pulleys and belts regularly for signs of wear
(visual inspection).
f Have worn pulleys replaced by the bicycle dealer.
f Have worn belt replaced by bicycle dealer.
3
1
2
Abb.: 7 Possible signs of wear on the belt drive
1. Belt
2. Front pulley
3. Rear pulley
4.2.2 Cleaning and care
f Keep components of the belt drive free of dirt or clean
them regularly and check the belt tension regularly to
avoid loss of function of the belt drive.
f Clean the profiles of the belt and pulleys with a soft
brush.
