Chapter 2 Hardware Installation
2.3 I/O Module Wiring
A plug-in screw terminal block is used for the interface between I/O modules and field
devices. The following information must be considered when connecting electrical
devices to I/O modules.
 The terminal block accepts Wire Size #16~28 AWG (stripped length: 6.5 mm)
 Always use a continuous length of wire; do not combine wires
 Use the shortest possible wire length
 Use wire trays for routing where possible
 Avoid running wires near high-energy wiring
 Avoid running input wiring proximal to output wiring
 Avoid creating sharp bends in the wires
Note! The wires should be at least 2 mm in diameter.
