Chapter 3 Introduction to Digital I/O
3.1.5 Modbus
ADAM-6350
AI 0 AO 0 DI 18 DO 18
Addres
s (0x)
chan-
nel
Descrip-
tion
Attri-
bute
Addres
s (0x)
chan-
nel
Descrip-
tion
Attri-
bute
Addres
s (0x)
chan-
nel
Descrip-
tion
Attri-
bute
0x0001 0
DI Value
Read
0x0033 0
DO Value
R/W
0x0065 12
DI Stop/
Start
Counter
R/W
0x0002 1 0x0034 1 0x0066 13
0x0003 2 0x0035 2 0x0067 14
0x0004 3 0x0036 3 0x0068 15
0x0005 4 0x0037 4 0x0069 16
0x0006 5 0x0038 5 0x0070 17
0x0007 6 0x0039 6 0x0071
0x0008 7 0x0040 7 0x0072
0x0009 8 0x0041 8 0x0073 12
DI clear
counter
R/W
0x0010 9 0x0042 9 0x0074 13
0x0011 10 0x0043 10 0x0075 14
0x0012 11 0x0044 11 0x0076 15
0x0013 12 0x0045 12 0x0077 16
0x0014 13 0x0046 13 0x0078 17
0x0015 14 0x0047 14 0x0079
0x0016 15 0x0048 15 0x0080
0x0017 16 0x0049 16 0x0081 12
DI
enable/
disable
filter
R/W
0x0018 17 0x0050 17 0x0082 13
0x0019 18 0x0051 18 0x0083 14
0x0020 19 0x0052 19 0x0084 15
0x0021 20 0x0053 20 0x0085 16
0x0022 21 0x0054 21 0x0086 17
0x0023 22 0x0055 22 0x0087
0x0024 23 0x0056 23 0x0088
0x0025 24 0x0057 24 0x0089 12
DO start/
stop
pulse
R/W
0x0026 25 0x0058 25 0x0090 13
0x0027 26 0x0059 26 0x0091 14
0x0028 27 0x0060 27 0x0092 15
0x0029 28 0x0061 28 0x0093 16
0x0030 29 0x0062 29 0x0094 17
0x0031 30 0x0063 30 0x0095
0x0032 31 0x0064 31 0x0096
