Advantech ADAM-6300 Series User Manual

ADAM-6300 User Manual 10
3.1 Specifications
3.1.1 General
 Power input: 10 ~ 30 V
DC
 LAN: 10/100Base-T(X)
 Connectors: 2 x RJ-45 (LAN), 1 MAC ID; Plug-in screw terminal block (I/O and
power)
 Screw terminal block: Accepts wire size #16-28 AWG, stripped length: 6.5 mm
 Watchdog: System and Communication
 Real-time clock accuracy: 2 seconds per day
 Certification: CE, FCC
3.1.2 Protection
 Power Reversal Protection
3.1.3 Environment
 Operating temperature: -25 ~ 70 °C (-13 ~ 158 °F)
 Storage temperature: -40 ~ 85 °C (-40 ~ 185 °F)
 Operating humidity: 20 ~ 95% RH (non-condensing)
 Storage humidity: 0 ~ 95% RH (non-condensing)
3.1.4 OPC UA Specification
 Support Address Space
 Session, Monitored item and Subscription
 Security Policy
An endpoint security policy is a predefined communication mode that mandates a
combination of security algorithms and optionally message signing and encryption.
– Endpoint Security Policy: None
– Endpoint Security Policy: Sign - Basic128Rsa15
 Authentication Policy
– User Token Anonymous - Token Security Policy None
– User Token Username / Password - Token Security Policy Basic128Rsa15
 Supports 8 certificates
Items Max Remark
Max Monitored Items 600 Including all sessions
Max Sessions 4
The maximum sessions supported, includ-
ing security and non security session.
Max Subscriptions per Session 1
Note! ADAM-6300 supports 4 session including security and non security ses-
sion. User can disconnect session and restart ADAM-6300 to remove
sessions you don't need.
Note! ADAM-6350 supports 8 certificates. User can click Delete Certificates
and restart ADAM-6350 to remove certificates you don't need.
