TPC-1570H User Manual 2
Chapter 1 General Information
This chapter gives the background information about the TPC-1570H.
1.1 Introduction
The TPC-1570H touch panel computer is state-of-the-art HMI (Human
Machine Interface). This 15” display operator interface is an x86-based
platform with these key features:
Fanless:
By using a low power processor, the system does not have to rely on fans,
which often are unreliable, and causes dust to circulate inside the equip-
ment.
Bright Display:
The bright TFT LCD display suits industrial demands for clear interfaces.
Powerful Communication Capability:
The TPC-1570H provides powerful IO interface for easily
communicating with other devices. The IO interface includes serial
ports, RS-485 port, parallel port, Ethernet and USB 2.0 support.
Embedded Windows Support:
In addition to the OS support of Windows 2000 and Windows XP,
Advantech offers platform support for Windows CE and XP embedded.
1.2 Specifications
1.2.1 System Kernel
CPU: Intel Celeron M (clock rate 600MHz /1GHz), Pentium M 1.4GHz
BIOS: Award 4Mbit flash memory
South Bridge: Intel 855GME/ 852GM GMCH/ICH4 chipset
VGA: Intel 855GME for TPC-1570H-P2AE, C1AE series; Intel 852GM
for TPC-1570H-B1AE series; Support 16 MB frame buffer with system
memory; Simultaneously support of CRT and LVDS flat panel display.
Ethernet: Intel 82562EZ and Intel 82551QM Ethernet controller; IEEE
802.3u protocol compatible
Watchdog timer: W83627 watchdog timer; 1 ~ 255 sec (system)
IDE: 2 EIDE channels support one IDE compact flash socket on board
and one 44 pin (2mm) connector transfer to SATA HDD interface (SATA
HDD only support data transfer rate of 1.5Gbits/sec).
