AEC IST5015 - Parallel Operation System; Parallel System Diagram

IST5 Tower UPS 10kVA~40kVA User Manual 39
Operations
UPS1
Load Connected
Output Power Supply
Power Supply
UPS2 UPS3 UPS4
Fig. 5-6 Parallel diagram
The parallel board is located at the back of the UPS cabinet, as is shown in Fig.5-7.
